Water Discharge Rubber Hose

Inner Tube：black EPDM or NR&SBR synthetic rubber (UPE layer is available) Reinforcement：multi-spiraled high tensile synthetic fibers Outer Layer：oil, abrasion resistant, anti-aging black, gray or blue NBR or PVC synthetic rubber Temperature Range：-30°C~82°C (-22°F~180°F) *The hose dimension, pressure and color can be customized based on the requirements：

Inner Tube：black EPDM or NR&SBR synthetic rubber (UPE layer is available)
Reinforcement：multi-spiraled high tensile synthetic fibers
Outer Layer：oil, abrasion resistant, anti-aging black, gray or blue NBR or PVC synthetic rubber
Temperature Range：-30°C~82°C (-22°F~180°F)
*The hose dimension, pressure and color can be customized based on the requirements：

[email protected]

+8613140502916

Consult Online Leave a Message

Product Attributes

Application：Designed for the general use of construction, agriculture, and other industrial applications.
Inner Tube：black EPDM or NR&SBR synthetic rubber (UPE layer is available)
Reinforcement：multi-spiraled high tensile synthetic fibers
Outer Layer：oil, abrasion resistant, anti-aging black, gray or blue NBR or PVC synthetic rubber
Temperature Range：-30°C~82°C (-22°F~180°F)
The hose dimension, pressure and color can be customized based on the requirements：

Product Parameters

I.D		O.D		W.P	Min.B.P	W.T
in	mm	in	mm	psi	psi	kg/m
2	51	2.4	61	45	113	1.4
2.5	64	2.91	74	45	113	2.1
3	76	3.43	87	45	113	2.45
4	102	4.57	116	45	113	4.35
5	127	5.51	140	45	113	6.2
6	152	6.46	164	45	113	6.75
8	203	8.82	224	45	113	14.75
10	254	10.94	278	45	113	19.75
2	51	2.4	61	75	188	1.4
2.5	64	2.91	74	75	188	2.1
3	76	3.43	87	75	188	2.45
4	102	4.57	116	75	188	4.35
5	127	5.51	140	75	188	6.2
6	152	6.46	164	75	188	6.75
8	203	8.82	224	75	188	14.75
10	254	10.94	278	75	188	19.75
2	51	2.48	63	150	375	1.5
2.5	64	2.99	76	150	375	2.2
3	76	3.5	89	150	375	2.55
4	102	4.65	118	150	375	4.45
5	127	5.59	142	150	375	6.3
6	152	6.54	166	150	375	6.85
8	203	8.9	226	150	375	14.85
10	254	11.02	280	150	375	19.85
